1. Using specialized layout software, simply select the style of the air duct to be cut in the software, input the corresponding size, and it can automatically generate expanded graphics, automatic layout, and automatic generation of cutting program code. It can be transferred to the cutting machine for cutting processing through a USB flash drive.
2. Plasma and flame cutting methods can be configured according to user needs.
3. Equipped with automatic seam compensation function
4. It is possible to perform the original trajectory fallback processing operation 5. Can perform power outage recovery operation
6. It can assist in nesting and automatic sorting, thus achieving continuous batch cutting
7. The system has high reliability and can self diagnose faults
8. Automatic deceleration at corners to better improve cutting quality
| Model | Board Thickness | Thickness | Cutting Width | Power | Cutting Speed | Weight | Dimensions |
| WY-QG J-11 | 4000mm | 0.4-5mm | 1500mm | 12KW | 0-12000mm/min | 660kg | 2350*1520*1980mm |
